Bom Pcb Assembly Fabrication And Assembly Circuit Board Manufacturers
Shenzhen Yideyi Technology Co., Ltd. provide full Turn-Key and partial Turn-Key Circuit Board Assembly Services continually upgrading our full feature PCB service with better equipment, more training and more efficient techniques to provide the highest quality, full feature PCB manufacturing and assembly for our clients.
We utilize all our manufacturing and supply chain expertise to bring you a complete all-in-one service.
What we can do:
Flying Probe Test, X-ray Inspection, AOI Test, Function Test
Stencil,Cable and Enclosure Assembly
Reverse engineering service
Fast PCB Fabrication for Samples and Mass Production
Electronic Components Sourcing Services
PCBA Assembly Services: SMT, DIP, BGA
PCB Base Materials:
1. RoHS Compliant Options
2. High Speed Digital Options
3. High Frequency RF Options
4. High Temperature Options
5. Aluminum Clad Options
Our Advantage:
1. Free programming and free functional test, free package.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% funtional test.
3. Professional service. ISO SMT and through hole assembly, over 10 years experience.
4. Certification for electronics: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001
5. Warranty period for PCBA: 2 years.
6. professional engineers
Production Requirement for pcb assembly:
1.Gerber Files (Eagle and PCB File are available).
2.BOM list.
3.Clear pictures of PCBA or PCBA samples to us.
4.Pick N Place file.
5.Test procedure for PCBA.
PCB Assembly Capacity:
| Items | Capability |
| Base Material | FR4, High Tg FR4, Halogen Free, Rogers, Aluminium |
| Finished Board Thickness | 0.2mm ~ 7.0mm(8mil-276mil) |
| Aspect Ratio | 10:1 |
| Copper Thickness | 1/3oz ~ 7oz |
| Surface Finishing | HASL, Lead Free HASL, Immersion tin, Immersion gold, Gold plating, Immersion silver, OSP, Carbon ink, etc. |
| Min. Trace Width/Space | 0.075/0.075mm(3/3mil) |
| Min. Finish Holes Size | 0.1mm(4mil) for laser holes; 0.2mm(8mil) for mechanical holes |
| Max.Finshed Size | 600mm x 900mm (23.6" x 35.43") |
| Hole Tolerance | PTH:±0.076mm(+/-3mil), NTPH:±0.05mm(+/-2mil) |
| Soldermask Color | Green, White, Black, Red, Yellow, Blue, |
| Impedance Control | +/-10% |
| Hole tolerance | PTH:±0.076,NTPH:±0.05 |
| Reference Standard | IPC-A-600H Class 2, Class 3 |
| Certificate | UL, ISO9001, ROHS, SGS |
You benefit:
We know exactly where we can purchase the components you need.You don't need to look around for suppliers. All you need is only an inquiry or an email.We can help you solve with anything else. With our understanding of the market and our bulk procure-ment advantages,effectively reduce your procurement costs. Instead of facing multiple vendors for a single product,we help you solve all of them.We are in charge of purchasing and quality .
1. Save time
We know exactly where we can purchase the components you need.You don't need to look around for suppliers.
2. Save labour
All you need is only an inquiry or an email.We can help you solve with anything else.
3. Save money
With our understanding of the market and our bulk procure-ment advantages,effectively reduce your procurement costs.
4. One-stop service
Instead of facing multiple vendors for a single product,we help you solve all of them.We are in charge of purchasing,quality inspection and stock management.
With our many years of experience,we have built an excellent core team from PCB processing,compent procurement,SMT assembly and finished product testing.We try our best to serve every company.We will always
uphold our service philosophy.win-win,efficient and convenience.
Fast PCB Fabrication for Samples and Mass Production
Electronic Components Sourcing Services
PCBA Assembly Services: SMT, DIP, BGA
